Protects fibre quality
Cleans gently and efficiently
Reduces trash content
Removes seed coats, leafy matter, short fibres, microdust etc. from ginned lint.
Improves lint grade & appearance.
Made with superior technical know-how.
Robust construction; longer life.
FEATURES & BENEFITS
Removes seeds coats, leafy matter after ginning.
Improves lint grade & appearance.
Reduces trash content & other contamination.
Eliminates micro-dust effectively.
Precise design preserves fibre properties.
Removes short fibre clusters from ginned lint.
Better quality lint yields higher returns.
Easy to maintain; Low maintenance cost.
Available in different models with different feeding systems for specific requirements.
Can be incorporated in pneumatic conveying system for online cleaning.
Considerable saving in labour cost.
top
TECHNICAL SPECIFICATIONS
Model I
Model II
Model III
No. of cleaning cylinders
Six
Three
Four
Width
1200/1500/
1800 mm
1200/1500/
1800 mm
1200/1500/
1800 mm
Type
Inclined
Inclined
Inclined
Cleaning Capacity (Lint)
1200/1500/
2000 Kg/Hour
1200/1500/
2000 Kg/Hour
1200/1500/
2000 Kg/Hour
Connected total power
7 HP
7 HP
7 HP
Bypass Arrangement
Provided
Provided
Provided
Wheel-mounting
(optional)
Yes
Yes
Yes
Feeding system
Mechanical/
Pneumatic/
Manual
Mechanical/
Pneumatic/
Manual
Mechanical/
Pneumatic/
Manual
